WS-1182 Intel® Core™ X-Series Workstations

Details & Specifications

Dimensions:

Item Depth (CM)	45.3
Item Height (CM)	41.3
Item Weight (Kg)	16-20
Item Width (CM)	21

Front IO:

# Front 3.5mm Audio Jacks	2
# Front USB 3.2 Gen 1 Type-A	2

Internal IO:

# Int USB 2.0 Header	2
# Int USB 3.2 Gen 2 Header	1
# Int USB 3.2 Gen1 Header	2
# M.2 NVMe PCIe 3.0 x4	2
# M.2 NVMe PCie 3.0 x4 / SATA	1
# SATA3 (6Gbps) Ports	8

Memory:

# Memory Slots	8
DDR Rev.	DDR4
Max. Memory Capacity (GB)	256
Max. Memory Channels	4
Memory Type	Non-ECC UDIMM

PCIe:

PCIe Configuration	3 x PCIe 3.0/2.0 x16 (x16, x16/x16, x16/x16/x8)

Processor:

Processor Generation	Intel® Core™ X-Series Processors
Socket	Socket 2066
Processor Chipset	Intel® X299

Rear IO:

# Optical S/PDIF	1
# PS/2 port(s)	1
# Rear 1Gbps RJ45 Ports	1
# Rear 3.5mm Audio Jacks	5
# Rear USB 2.0 Type-A	2
# Rear USB 3.2 Gen 1 Type-A	4
# Rear USB 3.2 Gen 2 Type-A	1
# Rear USB 3.2 Gen 2 Type-C	1

Software:

Supported OS	Linux, Windows

Storage Bays:

# Int 3.5inch SATA	2

Warranty:

Warranty Duration	36
Warranty Type	Return To Base Next Business Day Engineer Response
