16″ WS-M IC-M PRO Intel Core i7-14700HX, NVIDIA RTX 2000 Ada 8GB GDDR6 Mobile Workstation

Details & Specifications

Audio:

# 3.5mm Jacks	1x Mic-in/Headphone-out Combo Jack
Speakers	2x 2W Speaker

Dimensions:

Dimensions (WxDxH)	359 x 266.44 x 21.81~27.75 mm
Item Weight (Kg)	2.38Kg Including Battery

External IO:

# 1Gbps RJ45 Ports	1
# HDMI	1x HDMI™ 2.1 (8K @ 60Hz / 4K @ 120Hz)
# USB 3.2 Gen 1 Type-A	3
# USB 3.2 Gen 2 Type-C	1 (USB3.2 Gen2 / DisplayPort™/ Power Delivery 3.0)
Webcam	HD type (30fps@720p) 3D Noise Reduction (3DNR)

GPU:

# CUDA Cores	3072
# RT Cores	24
# Tensor Cores	96
GPU - Memory Type	GDDR6
GPU Architecture	Ada Lovelace
Integrated GPU Model	NVIDIA RTX 2000 Ada Generation Mobile
Lithography	5 nm
Memory Bandwidth	256 GB/s
Memory Capacity	8 GB
Memory Interface	128 bit

Internal IO:

# M.2 NVMe PCIe 4.0 x4	1
# M.2 NVMe PCIe 5.0 x4	1

Keyboard And Mouse:

Backlit Keyboard	Backlit (White)
Keys	Copilot Key

Memory:

# Memory Slots	2
DDR Rev.	DDR5
Max. Memory Capacity	96 GB
Max. Memory Channels	2
Max. Supported Memory Frequency	5600 MHz
Memory - Memory Type	Non-ECC
Memory Form Factor	SODIMM

Network:

Bluetooth Details	Bluetooth v5.3
WiFi Details	802.11 ax Wi-Fi 6E

Power:

AC Adapter	180W adapter
Battery	4-Cell 65 Battery (Whr)

Processor:

# Cores	20 (8 P-Cores, 12 E-Cores)
# Threads	28
Intel Smart Cache	33 MB
Max Boost Clock Speed	5.5GHz P-Cores, 3.9Ghz E-Cores
Processor Generation	Intel® Core™ i7 Processors (14th gen)

Screen:

Screen Native Resolution	2560×1600
Screen Refresh Rate	240 Hz
Screen Size (inch)	16
Screen Type	IPS

Warranty:

Mfr Warranty Length (M)	36 Months (12 Months Battery)
Mfr Warranty Type	Full Parts & Labour – Return To Base
