16″ 300Hz QHD+ Mini-LED 100% DCI-P3 Screen with Intel Core Ultra 9-275HX Processor & NVIDIA GeForce RTX 5080 16GB Graphics Card [X6AR558Y]
SKU: 16" WS-M IC-A U9-275HX RTX5080
In Stock
System Configuration
In Stock
Details & Specifications
Details & Specifications
Audio:
| Chipset |
Nahimic Audio |
|---|---|
| Connections |
Microphone-in and headphone-out |
| Integrated Microphone |
Yes |
| Speakers |
2 x 2W Stereo Speakers (2 channel HD Audio) |
Cooling:
| Active Cooling |
Yes |
|---|---|
| Liquid Cooling Port |
Yes |
Dimensions:
| WxDxH |
357mm x 245mm x 28mm |
|---|
External IO:
| Card Reader |
3-in-1 Card Reader (SD/SDHC/SDXC) |
|---|---|
| DC-in |
1 |
| Display |
1 x HDMI 2.1 (4K 60Hz), 1 x Thunderbolt™ 4 |
| Headphone-OUT |
1 |
| LAN |
1 x RJ-45 jack (2.5 Gigabit) |
| Microphone-IN |
1 |
| USB |
1 x Thunderbolt™ 4 Port, 1 x USB 3.2 Gen 2 Port (Type-C), 3 x USB 3.2 Gen 2 Ports |
| Webcam |
IR+FHD Hybrid webcam Windows Hello 4.0 |
GPU:
| # CUDA Cores |
7680 |
|---|---|
| # RT Cores |
60 |
| # Tensor Cores |
240 |
| GPU Architecture | |
| Integrated GPU Model |
NVIDIA GeForce RTX 5080 |
| Lithography |
TSMC 4NP |
| Memory Capacity |
16 GB |
| Memory Interface |
256 bit |
| Memory Type |
GDDR7 |
Internal IO:
| # M.2 NVMe PCIe 4.0 x4 |
1 |
|---|---|
| # M.2 NVMe PCIe 4.0 x5 |
1 |
Keyboard And Mouse:
| Backlit Keyboard |
Yes |
|---|---|
| Keys |
Per-Key RGB Keyboard with N-Key Roll Over |
| Language Support |
Multi-Language support |
Memory:
| # Memory Slots |
2 x Modules |
|---|---|
| Max. Memory Capacity |
96GB |
| Memory Type |
Supports up to DDR5 6400MHz |
Network:
| Bluetooth |
Bluetooth V5.3 module support |
|---|---|
| WiFi |
Wireless LAN 802.11AC/B/G/N (M.2 Interface) |
Power:
| Battery Capacity |
Lithium-ion 99WH |
|---|---|
| Battery Type |
Integrated |
| Power Lead & AC Adapter |
1 x Power Lead included with AC Adapter |
| Typical Battery Life |
Up to 5 Hours (in UMA mode) |
Processor:
| # Cores |
24 (8 Performance, 16 Efficient) |
|---|---|
| Cache |
36 MB |
| Efficient-core Max Turbo Frequency |
4.6 GHz |
| Integrated CPU Model |
Intel® Core™ Ultra 9 Processor 275HX |
| L2 Cache |
40 MB |
| Max Turbo Frequency |
5.4 GHz |
| Performance-core Max Turbo Frequency |
5.4 GHz |
Screen:
| Backlight |
LED | Mini LED |
|---|---|
| Brightness |
500 / 1250 Nits |
| Native/Maximum Resolution |
2560 x 1600 |
| Refresh Rate |
300Hz |
| Screen Size |
16 inch, 16:10 panel |
Security:
| Kensington Lock Support |
Yes |
|---|
Warranty:
| Mfr Warranty Length (M) |
36 Labour, 18 Parts, 12 Screen, 6 Battery |
|---|---|
| Mfr Warranty Type |
Return to Base |
